Model | Maximum Loading Height mm | Tank Size (w*l*h)mm | External Size (w*l*h)mm | Tank Volume lt | Loading Weight kg |
---|
AutoClean 200 | 300 | 430*890*490 | 924*1450*1100 | 200 | 75 |
AutoClean 300 | 400 | 550*890*630 | 1190*1530*1170 | 300 | 250 |
AutoClean 400 | 400 | 650*1180*650 | 1290*1830*1170 | 500 | 250 |
AutoClean 600 | 450 | 750*1330*700 | 1390*1980*1220 | 680 | 250 |
AutoClean 800 | 650 | 750*1330*900 | 1390*1980*1420 | 960 | 500 |
AutoClean 1000 | 650 | 800*1580*890 | 1440*2650*1280 | 1200 | 500 |
AutoClean 1300 | 900 | 800*1580*1200 | 1440*2750*1580 | 1580 | 500 |
AutoClean 2000 | 900 | 950*1850*1200 | 1600*3000*1580 | 2100 | 900 |
AutoClean 3000 | 1000 | 1100*2100*1300 | 1750*3250*1700 | 3100 | 900 |
AutoClean 4500 | 1000 | 1450*2700*1300 | 2100*3900*1700 | 5000 | 900 |
AutoClean 6000 | 1000 | 1600*3200*1300 | 2250*4400*1700 | 6600 | 1500 |
AutoClean 9000 | 1200 | 1700*3700*1500 | 2400*4800*1900 | 9300 | 1500 |
***Contact us for more technical information
» Space saving
» Cost saving
» Environmentally friendly
» Energy efficient
» Suitable for heavy items
» Manual installation
» Designed for delicate cleaning.
» Low water liquid level protection which stops the machine automatically
» Cleaning time and temperature are adjustable
» Can be integrated into the serial production line (optional)
Washing steps:» The entire process takes place in a single tank.
Addable Features» Dual and multi frequency ultrasonics available at request
» AISI 316L or AISI 316T stainless steel can be used
» Oil separation
» Pump filtration
» Automatic water filling/draining
» Pump circulation
» Chemical dosing systems
» Pneumatic oscillating platform
» Other system features
***All our AutoClean Washing Systems can be custom designed in line with the needs of our customers. Contact us for your special needs...
-
